ASF H3 Series

Off Grid Solar Inverter

8-12KW | Three Phase | 2 MPPTs
ASF H3 Series 8-12KW

Efficient

Dual MPPT with up to 99.9% efficiency.Up to 800V PV input voltage, ideal for high power.
ASF off grid inverter three phase (5).png
ASF off grid inverter three phase (6).png

Reliable

Outputs high quality pure sine wave AC power. 8-12kW load power to meet the needs of most households

Convenient installation

Industrial design with a modern aesthetic look.Easy to install and simple to use.
ASF off grid inverter three phase (1).png

Safety

360 degrees of security from hardware to software. IEC、FCC and other safety approvals

All in One

The 400V three-phase system is effcient, reliable andideal for large equipment, providing energy and costsaving

Intelligent

Exclusive Li-jon battery BMS dual activation.Time-slot function to save cost with peak-valley tariffs.

OVERVIEW

ASF off grid inverter three phase (2).png
Model
ASF4880SH3
Rated Output Power
8,000W
Max.Peak Power
16,000W
Rated Output Voltage
230/400Vac
Load Capacity of Motors
5HP
Rated AC Frequency
50Hz/60Hz
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
800Vdc/800Vdc
Model
ASF48100SH3
Rated Output Power
10,000W
Max.Peak Power
20,000W
Rated Output Voltage
230/400Vac
Load Capacity of Motors
6HP
Rated AC Frequency
50/60Hz
Num. of MPP Trackers
2
Max.Voltage of Open Circuit
800Vdc/800Vdc
Model
ASF48120SH3
Rated Output Power
12,000W
Max.Peak Power
24,000W
Rated Output Voltage
230/400Vac
Load Capacity of Motors
6HP
Rated AC Frequency
50Hz/60Hz
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
800Vdc/800Vdc
