ASF/ASP Series

Off Grid Solar Inverter

8-10KW | Single/Split Phase | 2 MPPTs
Download PDF Contact
ASF/ASP Series 8-10KW
Home | Solar Power Inverter| Off Grid Solar Inverter

Efficient

Dual MPPT with up to 99.9% efficiency.Up to 22A PV input current perfect for high power modules

Reliable

Outputs high quality pure sine wave AC power. 8-10kW load power to meet the needs of most households

Convenient installation

Industrial design with a modern aesthetic look.Easy to install and simple to use.

Safety

360 degrees of security from hardware to software. EU and North American safety approvals.

Intelligent

Exclusive Li-ion battery BMS dual activation. Time-slot function to save cost with peak-valley tariff.

Communication

Support various brands of battery communication.

OVERVIEW

Model
ASF4880U180-H
Rated Output Power
8,000W
Max.Peak Power
16,000W
Rated Output Voltage
120Vac/240Vac
Load Capacity of Motors
5HP
Rated AC Frequency
50Hz/60Hz
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
500Vdc+500Vdc
Model
ASF48100U200-H
Rated Output Power
10,000W
Max.Peak Power
20,000W
Rated Output Voltage
120Vac/240Vac
Load Capacity of Motors
6HP
Rated AC Frequency
50/60Hz
Num. of MPP Trackers
2
Max.Voltage of Open Circuit
500Vdc+500Vdc
Model
ASF4880S180-H
Rated Output Power
8,000W
Max.Peak Power
12,000VA
Rated Output Voltage
230Vac
Load Capacity of Motors
5HP
Rated AC Frequency
50Hz/60Hz
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
500Vdc+500Vdc
Model
ASF48100S200-H
Rated Output Power
10,000W
Max.Peak Power
15,000W
Rated Output Voltage
230Vac
Load Capacity of Motors
6HP
Rated AC Frequency
50/60Hz
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
500Vdc + 500Vdc
Model
ASP4880S180-H
Rated Output Power
8,000W
Max.Peak Power
12,000W
Rated Output Voltage
230Vac
Rated AC Frequency
50/60Hz
Permitted parallel number
1~6(single/three phase)
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
500Vdc+500Vdc
Model
ASP48100S200-H
Rated Output Power
10,000W
Max.Peak Power
15,000W
Rated Output Voltage
230Vac
Rated AC Frequency
50/60Hz
Permitted parallel number
1~6(single/three phase)
Num. of MPPT Trackers
2
Max.Voltage of Open Circuit
500Vdc+500Vdc
